Terra-Riser Series EABH Harrows

14" Disc Spacing: 2 1/8" (53.9 mm) axle - Weight per disc: 427 lbs average

Specifications:

Model	Number of Discs	Cutting Width (ft)	HP Motor Req'd*	Weight (lbs)
EABH 10 EABH 12 EABH 14 EABH 16 EABH 18 EABH 20 EABH 24 EABH 28 EABH 32 EABH 36	10 12 14 16 18 20 24 28 32 36	6' 7' 2" 8' 6" 9' 6" 10' 6" 11' 10" 14' 16' 18' 4" 20' 6"	110-120 120-140 140-160 160-190 190-220 220-240 260-300 310-330 330-350 350-370	4,305 4,780 5,522 6,776 7,524 8,897 10,227 11,962 13,212 13,893

Heavy duty structural steel mainframe

0 to 45 degree hydraulic angle control

Front - Rear Stabilizers

2 1/8" high strength round axles

Steel spacers and scrapers

Heavy duty US made Timken roller bearing assemblies

^* Horsepower may vary according to soil conditions or difficult terrain.

Applications:

Soil preparation for planting

Pulverization

Aeration

Standard Equipment:

Hydraulic angle control

Steel disc scrapers

32" (813 mm) diameter, 3/8" (9.5 mm) thick notched discs

Optional Equipment:

30" x 3/8" notched discs

Heavy duty wear plates

What makes our harrows better? We use the heavy duty Timken Roller Bearing in all our harrows - this bearing provides reliability as well as easy serviceability for the life of your Terra-Riser harrow.
